New Product IP65 Secure Validator 3G/4G WIFI Bluetooth EMV NFC Reader Bus Payment Scanner

The ACR350 Secure Validator is designed specifically for Automatic Fare Collection (AFC) systems to offer the convenience of cashless and secure payment in buses, ferries, trams, railways and other transportation modes.

This validator enables high-speed transaction processing through 13.56 MHz contactless (RFID) technology. It supports ISO 14443 Type A and B cards, ®, and FeliCa. Being certified with PCI PTS 5.1 with SRED, major payment standards such as PBOC Level 1 (Contactless) and EMV™ Levels 1 and 2 (Contactless) including MasterCard® Contactless and Visa PayWave®, this Validator offers flexibility and security to open-loop payment systems. The embedded barcode scanner enables transactions through the use of print or mobile barcodes or other QR payment applications.

It has advanced wireless connectivity options for data transfer such as GSM/GPRS, 3G/4G, and Wi-Fi. With an optional GNSS feature, it can be used to locate vehicles, manage fleets and set flexible distance-based fares. Protecting the bus validator from harsh environments is its IK08 rating for mechanical impact, IP65 rating for dust and water protection and the additional Military Standard MIL-STD-810 for Shock and Vibration.

Control Signals, Ignition sense and Bluetooth 5.1 are featured in this brand-new validator. With these new features, ACR350 could be a perfect choice for transit operators.

FEATURE

• Arm® Cortex®-A9 Quad-Core Processor at 1.0GHz running Linux®
• 32GB eMMC and 1GB RAM
• UPS via SuperCap (5 second interval after primary power source is lost)
• Military Standard MIL-STD-810 for Shock and Vibration
• IP65 Rating for Dust and Water Protection
• Expandable Micro SD Card support with memory up to 128 GB
• Connectivity Options
  • USB Host
  • Serial Port (RS-232, RS-485)
  • Ethernet Port
  • Wi-Fi
  • GPRS/GSM, 3G, and 4G1
  • Built-in 10/100/1000 Ethernet
  • Bluetooth 5.1 Dual Mode
  • GNSS2
  • GPIO Isolated ports (2 x input + 2 x output)
  • CAN BUS
  • Ignition Sense
• Smart Card Interface:
  • Contactless Interface:
• Read/Write speed of up to 424 kbps
• Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)
• Supports ISO 14443 Part 4 Type A and B cards, Classic®, and FeliCa
• Built-in anti-collision feature (only one tag is accessed at any time)
  • SAM Interface:
• Four SIM-sized Card Slots
• Supports ISO 7816 Class A, B, and C (5 V, 3 V and 1.8 V) cards
  • SIM Interface:
• One SIM-sized Card Slot for GPRS/3G/4G connectivity
• Built-in Peripherals:
  • 4.3-inch Easy-to-Read, TFT Colored LCD
  • Capacitive Type Touch Panel
  • Barcode Scanner (Linear/2D)3
  • Real-time Clock (RTC) with independent backup battery
  • 6 LED Status Indicators (Front: Blue, Orange, Green, and Red; Back: Green and Red)
  • User-controllable buzzer
• Compliance and certification
  • PCI PTS POI v5.1 with SRED
  • EMV® Levels 1 (Contactless)
  • PBOC Level 1 (Contactless)
  • MasterCard® Contactless
  • Visa payWave®
  • CE
  • FCC
  • REACH
  • RoHS

1 Please refer to full product specification for a more detailed frequency band support; Can be optional

2, 3 Can be optional

TECH SPEC
